Equus Soprema Duotherm Warm Roof System
Description

The Equus Soprema Duotherm Warm Roof a light-weight, thermal roofing system consisting of the Duo two-layer waterproofing membrane system applied over thermal insulation board and a vapour barrier. Duotherm guarantees a continuous and efficient thermal resistance (R-value) as per the NZ Building Code and is designed for use on exposed flat roofs and decks. The Duo system is CodeMark certified and BRANZ Appraised.

Duotherm provides a UV resistant, superior quality insulated waterproofing system with a fire retardant membrane, to meet the requirements and environmental challenges of the New Zealand climate.

With a range of components designed for different building requirements, Duotherm provides a customisable waterproofing solution that can be installed over a range of substrates to form an efficient warm roof in any area of the country.

Key Features

Advantages of Choosing a Warm Roof

  • Specific project design with condensation risk analysis (CRA) and wind load calculations to ensure the best system available for the buildings requirements.
  • Condensation Control – A warm roof moves the dew point to the outside of the structure, ensuring there is no condensation build up in the ceiling cavity.
  • No condensation build up negates the need for mechanical venting, causing less penetrations in the membrane.
  • Energy Cost savings are maximised with less need for heating or cooling throughout the building.
  • Creates more space within the ceiling for services.
  • Light-weight system, strong and flexible for resistance to seismic movement.

Advantages of Choosing the Duo membrane

  • Fire retardant membrane
  • Over 90 years proven performance worldwide
  • BRANZ appraised and CodeMark certified
  • 20 year warranty additional 20 year insurance backed manufacturer warranty
  • A high-tech, slate chip surface offering strong UV resistance and a tidy, aesthetic finish
  • Excellent durability and easy maintenance
  • Life expectancy of at least 35 years in all New Zealand climates
  • Green Roof options available

Equus Soprema Technical Support

  • Project specific specifications and details
  • Condensation risk analysis for warm roof systems
  • Wind uplift study for warm roof systems
  • On-site quality assurance
  • Nationwide network of Certified Applicators
  • Warranties available
Scope of Use

Duo is specifically designed for roofs, decks & balconies where thermal insulation is required. It is suitable for new builds and refurbishments, residential and commercial construction, in any location and wind zone in New Zealand.

Equus Soprema Warm Roofs have been appraised for use as an insulating roof or deck on buildings within the following scope:

  • the scope limitations of NZBC Acceptable Solution E2/AS1, Paragraph 1.1; or,
  • the scope limitations of NZBC Acceptable Solution E2/AS1, Paragraph 1.1 with regard to building height and floor plan area when subject to specific structural design; and,
  • situated in NZS 3604 Wind Zones up to, and including, Extra High.

Approved for substrate with finished falls of:

  • Roofs: Minimum 1:80 (0.7°)
  • Decks: Minimum 1:80 (0.7°)
  • Gutters: Minimum 1:100 (1%)

See BRANZ Appraisal 685 or CodeMark for full information.

Equus Soprema Warm Roof System has also been appraised for durability and thermal performance as an insulated roofing system on buildings that are the subject of specific design with no building height restriction.

See BRANZ Appraisal 1169 for full information.

Limitations on Use
  • Building designers are responsible for the building design and for the incorporation of Equus Soprema Warm Roof System into their design in accordance with the declared properties and instructions of Equus Industries Ltd.
  • Must be installed by Equus Industries Ltd approved and trained installers
  • In areas of regular foot traffic, higher than for normal maintenance traffic, the membrane must be overlaid with Fixplus pedestals and pavers or decking, Kraitec Step walkway tiles or other approved protection.

Statement of Building Code Compliance

In the opinion of BRANZ, Equus Soprema Warm Roof System, if designed, used, installed and maintained in accordance with the statements and conditions of Appraisal 1169, will meet or contribute to meeting the following provisions of the NZBC:

  • Clause B2 DURABILITY: Performance B2.3.1 (b) 15 years.
  • Clause E2 EXTERNAL MOISTURE: Performance E2.3.1 and E2.3.2.
  • Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1.
  • Clause H1 ENERGY EFFICIENCY: Performance H1.3.1 (a). Equus Soprema Warm Roof System contributes to meeting this requirement.

See BRANZ Appraisal 1169 for full information.

In-Service History

This system has over 20 years proven performance in NZ, over 90 years worldwide designed for use on exposed architectural flat roofs, podium decks, balconies, and terraces.

Other Performance Attributes
  • Warranty 20 years (25 years available) with the correct specification and installed by an Equus Certified Applicator
  • Additional 20 years insurance-back manufacturer warranty
  • Life expectancy of at least 35 years in all New Zealand climates
  • Easy to maintain
  • Fire retardant membrane, strong UV resistance, and shrink-free
BRANZ Appraised
BRANZ Appraised
CodeMark
CodeMark
Documents
Product Statement: Equus Soprema Duotherm Warm Roof System

2025

Equus Document Library
BRANZ Appraisal 1169: Warm Roofs

No 1169 [2021] amended 2024

BRANZ Appraisal 685: Soprema Duo

No. 685 [2021] amended 2023

CodeMark Certificate: Soprema Waterproofing Membrane Systems

CMNZ70151 2023
