Triton Fabwall Bass

Triton Fabwall Bass is a sound absorbing fabric wrapped acoustic wall or ceiling panel designed to provide an attractive finish and control unwanted low frequency noise.

Manufactured in NZ from bio-soluble glass wool absorber with impact resistant Sonatex interlayer and wrapped in a range of decorative fabric finishes (polyester, wool, other).

Key Features
  • High sound rating targeted for bass low frequency absorption
  • Provides a soft decorative finish to interiors
  • Rich palette of fabric finishes, textures and colours
  • Durable resilient composite construction for long life
  • Pre-fabricated for fast installation on site
  • Standard and custom sizes
  • Fire safe glass wool core, will not melt or burn like foam or polyester fibre panels
  • Fire Group 1-S (subject to fabric selection)
  • Low VOC, GreenTag certified / Level A
Green Tag Certified
Green Tag Certified
Recycled Content (Pre-Consumer)
Pre-Consumer Recycled Content
NZ Made
NZ Made
NZ-Owned Business
NZ-Owned Business
Scope of Use

Triton Fabwall 50/100/150 Bass are designed for low frequency absorption applications.

Limitations on Use
  • For interior use only, and not in direct contact with water
  • Maximum humidity/temperature 90% R/H at 30°C
  • Panels with digital printed fabric must not butt together due to image creep formed during the printing process. If large panel images are required then use Snaptex stretch fabric system with wide format fabric.
Statement of Building Code Compliance

NZ Building Act — This product is not subject to a warning or ban under Section 26.

NZ Building Code Compliance:

  • B2 Durability – Clause B2.3.1 (c) (i): Asona Triton Fabwall Bass with only normal maintenance will have a minimum durability of at least 5 years when installed in accordance with manufacturer’s installation requirements.
  • C3 Fire – Clause C/AS2 3.4(a): Asona Triton Fabwall Bass with polyester fabric has a Fire Material Group Number 1-S by NZBC verification method C/VM2 Appendix A, tested in accordance with ISO 5660 or ISO 9705. (NCC BCA C1.10 clause 4, spec A2.4 clause 4. Group 1). BRANZ test report FI-14081.
  • Other fabrics 2-S, 2 and 3. Please consult Asona.
Other Performance Attributes
  • Low VOC
  • GreenTag certified / Level A
B2 Durability compliant
C Protection from Fire compliant
Protection from Fire
Independent Assessment
Independent Assessment
Test Results
Test Results
Interior Fire Rating 1S

Asona Ltd are a manufacturer, distributor and installer of acoustic and decorative ceiling and wall panels.
