Triton Cloud Panel
Description

Triton Cloud™ panels are a New Zealand made high sound absorbing ceiling panel with wrapped edges for a crisp tailored finish.

Panels are rigid and designed as free floating or direct fix elements to control reverberation. Available in a range of standard and custom sizes, shapes and decorative finishes.

Composition

Made in NZ from non-combustible glass wool acoustic core with Sonatex™ acoustic laminate to 5 sides, tissue backed.

Key Features
  • Attractive clean panelised look with finished edges
  • High sound absorption, NRC 1.00, for noise control
  • Fire group 1-S rating
  • High light reflectance in standard white, plus decorative finishes for design freedom
  • Dimensionally stable, rigid finish, no sag in hot conditions
  • Wide range of mechanical fixing solutions to direct fix or suspend panels
  • Made in NZ, short lead times including replacement parts
  • Available in 25, 40, 50, 75, and 100mm thicknesses
  • Large modules available up to 1200mm x 3000mm
  • GreenTag Certified / Level A
  • ISO 9001 registered quality management program
  • Packaging take back and reuse scheme
Green Tag Certified
Green Tag Certified
Recycled Content (Pre-Consumer)
Pre-Consumer Recycled Content
NZ Made
NZ Made
NZ-Owned Business
NZ-Owned Business
Scope of Use
  • Designed as a free-floating acoustic ceiling panel or direct fixed ceiling or wall panel
  • Triton Cloud panels are ideal for ceilings in open office, classrooms, meeting rooms, halls, cafes and bars where control of noise is required
Limitations on Use
  • Not for external aaplication
  • Installation shall not commence until the building is water tight and dry
  • Light/mechanical fittings or other point loads shall be independently supported
  • Max 99% R/H at 45°C
Statement of Building Code Compliance
  • Fire Reaction - NZBC verification method C/VM2 material group number: 1-S. (NB: Based on Sonatex laminates. Fabric finishes will result in fire group rating 2-S, 2 and 3. Please consult Asona)
  • Clause B2—durability, 5 years
In-Service History
  • Multiple throughout NZ.
  • Saatchi & Saatchi, Auckland
  • Johnsonville Library Cafe
  • Scion, Rotorua
  • Sileni Vineyard, Hawkes Bay
Other Performance Attributes
  • NRC 0.75 - 1.00 acoustic absoption.
  • Global Green Tag Certified, Level A, Contains 80% recycled content, low VOC, soiled panels can be resurfaced with new acoustic facing to extend product life and reduce waste.
  • Light Reflectance - 85% per BS8493:2008, White, others subject to colour.
Independent Assessment
Independent Assessment
Test Results
Test Results
Documents
Asona Triton Cloud Panel

24.08

Environmental Information - GreenTag Level A

230413

Maintenance: Triton Range
Warranty
