Metapan P-Series Ceiling Tile
Description

MetaPan P lay-in ceiling tiles are designed to integrate with standard Rondo Donn 24mm and 15mm exposed grid systems Different height panels are available including 10mm, 15mm, 20mm and 30mm (Fig. A) which creates different visual effects, either with just one height or mixing different heights.

Manufactured from aluminium sheet, press formed and polyester powder coated. Additional absorber material can be added to meet acoustical requirements, please consult with Asona’s technical sales team.

Key Features
  • Washable powder coated finish
  • Easy Lay-in system, easy to reconfigure and access for maintenance
  • Durable long life system
  • Available in plain white, black, or woodprint finishes (or custom colours to order)
  • Wide range of tile height options and perforations
  • Preformed cut outs for easy service integration
  • Variable acoustic backing options
  • 1-S Fire Group rating. (ISO A1)
  • Different edges to suit Rondo DX 24mm and DC 15mm grid systems
NZ-Owned Business
NZ-Owned Business
Recyclable Content (Post-Consumer)
Post-Consumer Recyclable Content
Scope of Use

Ideal for civic, institutional and commercial buildings that require a long life, robust, accessible acoustical ceiling.

  • Transportation terminals, healthcare facilities or as a decorative ceiling for offices and hospitality
  • Easy Lay-in system, easy to reconfigure and access for maintenance
  • Variable acoustic backing options
  • Different edges to suit Rondo DX 24mm and DC 15mm grid systems
  • Suitable for fire exit way and all other sprinklered & non sprinklered buildings
Limitations on Use
  • Indent only, subject to lead times, consult Asona
  • Max 95% R/H at 45°C
  • Shall not commence until the building is water tight and dry
  • Max distributed load 1 kg/m², point loads shall be independently supported
Statement of Building Code Compliance
  • Fire Reaction — Material Group number: 1-S (ISO A1) C/VM2 / ISO 5660.1. Suitable for fire exit way and all other sprinklered & non sprinklered buildings
  • Clause B2—durability, 5 years
B2 Durability compliant
Durability
Interior Fire Rating 1S
1S
Test Results
Test Results
Documents
Asona Metapan P

23.12

Asona Ltd are a manufacturer, distributor and installer of acoustic and decorative ceiling and wall panels.
