GIB Toughline Aqua Brings Water-Resistance to Walls

GIB Toughline Aqua has been specially developed for situations that require multiple performance characteristics including impact, fire, noise, bracing, water and mould resistance.

Like GIB Toughline, GIB Toughline Aqua is a 13mm thick high-density plasterboard with a continuous fiberglass mesh embedded inside the back face of the board. This gives the board increased impact resistance and reduces repair costs. GIB Toughline Aqua has the additional benefit of a water-resistant core containing special polymers to help prevent steam and moisture penetration.

Winstone Wallboards recommends the use of GIB Toughline Aqua in situations where both impact and water resistance are required. By employing both GIB Toughline and GIB Toughline Aqua together, specifiers and contractors can utilise the most efficient and cost-effective board for the purpose, with water resistance only in areas that require that additional performance.

GIB Toughline Aqua can also be used as a multiple performance plasterboard to cover a wide range of performance situations, particularly for instances where a contractor would prefer fewer boards on site and higher performance generally across the project.

The performance of GIB Toughline Aqua is equivalent to GIB Superline, and any specifications that specify GIB Superline can use either GIB Superline or GIB Toughline Aqua as the product name transitions in the market.

GIB Wet Area Systems

GIB

View Product

Although able to cope with infrequent short-term exposure, standard gypsum plasterboard will have a shortened life expectancy when frequently exposed to water or moisture.

NZ Made

GIB Aqualine is ideal in situations where lining materials may be exposed more frequently to water or streams (particularly one-off events such as leakages or flooding of a room) because it features a water resistant wax polymer impregnated core.

Clause B1 Structure: The design and material specification for steel and timber framing used in GIB Aqualine systems must be in accordance with the performance requirements of NZBC Clause B1 (Structure).
Clause B2 Durability: When installed and maintained in accordance with this literature, GIB Aqualine tiled or vinyl covered systems have a serviceable life of at least 15 years. They comply with the requirements of NZBC Clause B2 for use in wet areas directly exposed to liquid water, e.g. showers, showers over baths and splash-backs. When used as a general wet area lining and maintained under normal dry internal conditions, GIB Aqualine systems have a serviceable life of at least 50 years and comply with NZBC Clause B2 for use within toilets, kitchens, bathrooms and laundries not directly exposed to liquid water.
Clause C3 Spread of Fire: GIB Fire Rated Systems provide passive fire protection in accordance with the requirements of NZBC Clause C3. When GIB Aqualine is substituted into fire rated systems in place of the equivalent thickness GIB Fyreline, the Fire Resistance Rating (FRR) of that system will be maintained.
Clause E3 Internal Moisture: When installed in accordance with this literature, tiled or vinyl covered GIB Aqualine systems may be used in areas directly exposed to liquid water, such as showers, to provide an impervious and easily cleaned wall surface.
Clause F2 Hazardous Building Materials: At no stage during handling, installation, or serviceable life does GIB Aqualine constitute a health hazard. It therefore meets the provisions of NZBC Clause F2.
Clause G6 Airborne and Impact Sound: GIB Noise Control Systems can be used to provide ratings for Sound Transmission Class (STC) and Impact Insulation Class (IIC) in accordance with the requirements of NZBC Clause G6.

All GIB unfinished plasterboard sheet materials achieve a Group 1-S interior fire rating to NZBC C/AS2-AS6, Table 4.1, following testing in accordance with ISO 5660.1 and ISO 5660.2.

Structure

Durability

Internal Moisture

Hazardous Building Materials

Airborne and Impact Sound

BRANZ Appraised
