Polyflor MiPlank Acoustic
Description

Polyflor MiPlank Acoustic has been specifically developed as a natural timber Luxury Vinyl Plank to assist specifiers with the key consideration of the reduction of Impact Sound in the residential and commercial sectors.

Available in 8 colours, the product thickness does not vary between the MiPlank and MiPlank Acoustic ranges, enabling interchangeability within projects where impact sound requirements may differ. Polyflor MiPlank Acoustic is available in a 5mm gauge with a .5mm wear layer in a variety of dimensions.

Key Features
  • Built-in IXPE acoustic backing
  • Up to 19dB impact sound reduction
  • 8 authentic replications of natural timber
  • PUR
  • Total thickness 5mm giving interchangeability with non-acoustic MiPlank range
Scope of Use

 Polyflor MiPlank Acoustic has been specially developed as a modern Luxury Vinyl Tile and Plank solution when impact sound reduction is a key consideration when specifying flooring options. Combining the high quality and design of traditional MiPlank with an acoustic backing that reduces impact sound by up to 19db, MiPlank Acoustic is suitable for installation to homes as well as a range of heavy duty commercial spaces, and provides the perfect solution for multi-storied residential applications where the reduction of impact sound forms part of the design requirements.

Product thickness does not vary between the MiPlank and MiPlank Acoustic ranges, enabling interchangeability within projects where impact sound requirements may differ.

Limitations on Use
  • Polyflor MiPlank Acoustic is designed for indoor use as a fully installed floorcovering.
  • Polyflor MiPlank Acoustic is not designed for wet or permanently immersed use, such as level entry access showers.
  • Polyflor MiPlank Acoustic is not designed for environments below -18 degrees celcius or above 60 degrees celcius. Refer Polyflor technical manual for recommendations around acclimatisation and installation in environments subject to thermal fluctuation.
  • Polyflor MiPlank Acoustic is suitable for installation over underfloor heating to a maximum of 27 degrees celcius, subject to installation instructions as per Polyflor Technical manual.
  • Polyflor recommends adequate UV protection from direct sunlight as fading may occur from exposure to our high UV in NZ.
Statement of Building Code Compliance
  • B2 Durability B2.3.1 (c) 5 years
    • Manufactured to EN649/EN ISO 10582 and EN651
  • C1 Protection from fire
    • EN 13501-1 Class Cfl-S1
    • AS ISO 9239-1 —Greater than 4.5kW/m²
  • D1 Access Routes
    • EN 13893 Class DS
    • AS 4586 — R10
    • DIN 51130 — R10
  • E2 External Moisture — Can be installed over subfloors reading 75% RH or less as per E2.2.2
  • E3 Internal Moisture — Polyflor MiPlank Acoustic installed in accordance with manufacturers recommendations and project specific BCA requirements is an alternative solution under Building Code Clause E3.3.3
  • F2 Hazardous Building Materials
    • Indoor Air Comfort Gold — Eurofins certified product
    • AgBB/ ABG VOC Test — Very Low Emissions
    • Floorscore — Certified
  • G6 Acoustic Impact Sound Reduction — EN ISO 10140-3; 19dB
In-Service History

Polyflor MiPlank Acoustic LVT has been used extensively in Europe, and has been successfully introduced to the New Zealand and Australian markets as design requirements for acoustic products evolve.

Other Performance Attributes

Polyflor MiPlank Acoustic forms part of a system to reduce Impact Sound in residential and light commercial applications. It is manufactured under strict ISO standards, and achieves a generic BRE Global Environmental A+ rating. Specific EN15804 EPD is available on request.

  • Abrasion resistance: EN660-2 Group T, ISO 10582 Type 1
  • Residual Indentation:  ISO 24343-1 (EN433) — Less than or equal to 0.20mm
  • Impact Sound Reduction: EN ISO 10140-3 — 19dB
  • Static Electrical Propensity: EN1815 — Less than or equal to 2.0kV Classified as anti-static
  • Dimensional Stability: ISAO 23999 (EN434) — Less than or equal to 0.25%
  • Light Fastness: ISO 105-B02 — Greater than or equal to 6
  • Thermal Resistance: EN 12677 — 0.0419m2/K/W
  • Castor chair (continious use): ISO 4918 (EN425) — Suitable
  • Polyflor MiPlank Acoustic is 100% recyclable and contains an average of 20% recycled material
Documents
Additional Information

Polyflor is a global manufacturer of design lead commercial and residential resilient floor coverings, and was the first floorcoverings manufacturer to receive Global Green Tag accreditation in 2010.
