• Safe access to roofs, ceiling spaces, and elevated platforms
• Suitable for commercial and industrial applications
• Recommended for single person use — 150kg rated
• Industrial rated, suited to high frequency use
• Configurable for vertical or angled access (up to 6.0m)
• Compatible with concrete, steel, or purlin mounting
• Structural requirements for attachment of rung ladders:

  • Steel purlin 100 x 1.5mm base metal thickness
  • Timber batten 70 x 35 F7 structural grade
  • Composite panel 75mm attached using through bolt system

• The preferred angle of rung ladders is 75°. Ladders positioned at 90° are permissible provided suitable fall protection is provided.
• An enclosed cage is the preferred method of fall protection for rung ladders above 3500mm.
• This system is not to be used for tethering or lifting machinery or equipment.
• Rung ladder landings must be provided at the base and top of ladders if the entry and exit surface is uneven or not level.
• It is important that the maximum vertical distance between landing platforms does not exceed 6.0m.
• Rung ladder support fixing brackets must be spaced at no greater than 3.0m on a vertical or angled ladder.
• Any distance greater than 3.0m between brackets, the rung ladder RL413 stile strengthener must be used.
• The ladder cage base height must be positioned between 2.0m - 2.2m measured vertically from where the cage attaches to the ladder.
• The safety system must be re-certified by a competent height safety inspector as recommended:

  • Non corrosive/mild environment — 12 monthly
  • Corrosive/harsh environment — 6 monthly (more frequent inspection may be required)

Designed to conform with requirements of the Australian & New Zealand Standards:

• AS 1657:2018;
• AS/NZS 5532:2013;
• AS/NZS/ISO22846;
• AS/ NZS1891 and;
• Relevant codes of practices and guidelines.

• Testing and performance based on requirements of Australian Standard AS1657:2018.

Warranty

• 10 years from date of purchase subject to correct installation.
• Use and maintenance to be in accordance with manufacturer’s specifications and recommendations.
• This excludes wearing parts.

The safety system must be re-certified by a competent height safety inspector as recommended:

• Non corrosive/mild environment — 12 monthly
• Corrosive/harsh environment — 6 monthly (more frequent inspection may be required)
