• Suited for fall arrest or twin rope access use.
• Maintenance access for building facades, roofs, and elevated structures.
• Capable of multi-directional use.
• Low profile with an option for powder coating.
• Options to use Structural Mount Mega Post for raised fall arrest or rope access systems above garden beds and other areas.

• Minimum structural requirements for attachment.
• Only to be used by competent persons with proof of training by a Registered Training Organisation (RTO) in the use of height safety and fall protection systems.
• The anchor is suitable for single (1) person use and rescue in the case of a fall incident. (15kN)
• Do not exceed the maximum number of users/persons per system. See specific system data plate for user configuration.
• This system is not to be used for tethering or lifting machinery or equipment.
• The safety system must be re-certified by a competent height safety inspector as recommended:

  • Non corrosive/mild environment — 12 monthly
  • Corrosive/harsh environment — 6 monthly (more frequent inspection may be required)

The anchor is designed and manufactured to conform to requirements of Australian and New Zealand Standards:

• AS/NZS 5532:2013;
• AS/NZS 1891.4:2009 and;
• Relevant statutory WHS Codes of Practice/ Guidelines.

Testing and performance based on requirements of Australian and New Zealand Standards:

• AS/NZS 5532:2013 and;
• AS/NZS 1891.4:2009.

Warranty

• 10 years from date of purchase subject to correct installation.
• Use and maintenance to be in accordance with manufacturer’s specifications and recommendations.
• This excludes wearing parts.

The safety system must be re-certified by a competent height safety inspector as recommended:

• Non corrosive/mild environment — 12 monthly
• Corrosive/harsh environment — 6 monthly (more frequent inspection may be required)
