Equus Soprema Antirock Carpark Membrane
Description

The Equus Soprema Anitrock waterproofing membrane is a top-of-the-line solution for waterproofing carpark decks, bridges and other civil engineering structures, finished with asphalt.

Composed of SBS-modified bitumen with a tough non-woven polyester reinforcement, and a slate finish, Antirock is a highly durable, wear-resistant waterproofing membrane. Antirock is specifically designed to withstand the challenges posed by a hot applied asphalt cover, making it the superior choice for reliable protection.

Key Features
  • Used directly underneath asphalt and ready for immediate paving
  • Total adhesion to the substrate by heat welding
  • High mechanical strength to withstand the movement of the supporting structure
  • Resistance to chemical and biological agents (hydrocarbons, salts, etc.)
  • Resistance to thermal shock and puncture
  • High elasticity with excellent tear and puncture resistance
  • Fast and secure installation by automated machine available in N

Equus Soprema Technical Support

  • Project specific specifications and details
  • On-site quality assurance
  • Nationwide network of Certified Applicators
  • Warranties available
Scope of Use

Antirock is specifically designed for heavy-duty applications in civil engineering projects. It is ideal for use on car park decks, bridge decks, tunnels, and other critical infrastructure where robust waterproofing and durability are vital. Antirock is installed over a concrete substrate and adhered either by gas torch, or by using the specifically designed Soprema Mini-Macaden machine and is overlaid by asphalt. It is suitable for new builds and refurbishments, residential and commercial construction, in any location and wind zone in New Zealand.

Suitable for other waterproofing applications with written approval by Equus Industries Ltd.

Limitations on Use

The asphalt overlay must be installed within one week of the Antirock membrane installation minimum, and the thickness of the overlay shall be 40 mm after compaction for light vehicles, or 60 mm after compaction for heavy vehicles. The maximum temperature of the asphalt installation is 200°C.

The product must be installed by a Certified Equus Applicator. Verification of their status can be confirmed by a current applicator certificate or by contacting Equus Industries. Any installation must be done in accordance with the latest specifications and technical documentation, or with written approval by Equus Industries Ltd.

Statement of Building Code Compliance
  • B2 Durability - B2.3.1 (b), ANTIROCK has a durability of at least 15 years when installed with the correct specification, installation and maintenance.
  • E2 External moisture - E2.3.1, E2.3.2, E2.3.7 Test data, together with in-service history internationally, of the correctly installed ANTIROCK membrane over correctly designed and constructed substrates, show that the membrane successfully resists the ingress of moisture.
  • F2 Hazardous building materials - F2.3.1 Well known experience with the type of materials used together with in-service history, show that ANTIROCK complies with this performance requirement. Refer to SDS at www.equus.nz

 See BRANZ Appraisal 685 for more information.

Documents
Product Statement: Equus Antirock Carpark System

2024

Equus Industries Ltd provide technical waterproofing, tanking, coating and flooring solutions for architects, engineers, property managers and contractors in the building industry.
