Ultimate Surfaces Heterogeneous Sheet Vinyl
Description

The Ultimate Surfaces vinyl range seamlessly blends contemporary design with everyday functionality. With a selection of stylish patterns and sophisticated tones each design in the range offers a perfect balance of style and performance. Ideal for residential and commercial spaces, this durable sheet vinyl adds a refined, modern touch to any environment.

  • Total Thickness: 2.8mm
  • Wearlayer Thickness: 0.35mm
Key Features
  • Good wet slip resistance — R10
  • Good impact sound reduction
  • Antistatic
Scope of Use
  • Suitable in heavy traffic residential areas such as hallways, kitchens, and living rooms
  • Suitable in medium traffic commercial areas such as classrooms, hotel rooms, and small offices
  • Suitable in accessways
  • Suitable in watersplash areas and within 1.5m of a sanitary fixture or appliance
  • Suitable for underfloor heating
Limitations on Use
  • Interior use only
  • Not suitable in heavy traffic commercial areas such as restaurants, hallways, and lobby areas—refer to other Belgotex commercial sheet vinyl ranges
  • Must be installed by a qualified installer
  • Installation to be undertaken to industry best practice guidelines
  • Must be maintained in line with Belgotex care and maintenance guidelines
  • Substrate must have 75% or less relative humidity
Statement of Building Code Compliance
  • B2.3.1(c): Ultimate Surfaces is manufactured to EN 14041 standard and meets the minimum durability requirement of 5 years
  • C3.4(b): Ultimate Surfaces has been tested against ISO 9239-1 standard achieving a CRF of 6.8kW/m²
  • D1.3.3(d): Ultimate Surfaces provides acceptable slip resistance for level access routes, slopes, and stairs expected to remain dry under normal use as per D1/AS1 Table 2
  • E3.3.3, E3.3.5: Ultimate Surfaces is considered an integrally waterproof sheet material under E3/AS1, 3.1.1(a)
  • F2.3.1: Ultimate Surfaces has been assessed to EN 14041 for low chemical emissions
In-Service History

Belgotex sheet vinyl has been installed in buildings in New Zealand for over 5 years, with most original installations still in service.

Other Performance Attributes
  • Impact Sound Reduction, ΔLw: 18 dB (ISO 717-2)
  • Slip Resistance: R10 (EN 16165 Annex B)
  • Class 23 Domestic Heavy / Class 32 Commercial Medium
  • 15 Year Residential Warranty / 10 Year Commercial Warranty
Test Results
Test Results
Documents
BPIR: Commercial Heterogeneous Sheet Vinyl
Data Sheet
Fire Test
Slip Test
Installation Guidelines: Sheet Vinyl
Care & Maintenance: Commercial Sheet Vinyl
Additional information

Belgotex are one of New Zealand’s leading flooring distributors, with a comprehensive collection of carpet, vinyl and timber flooring solutions.
