Bituthene® 3000
Description

Bituthene® 3000 is a self-adhesive membrane designed for use in below-ground construction where reliable protection from moisture is required. Known for its robust cross-laminated backing and ease of installation, Bituthene® 3000 provides a durable barrier that helps protect structures from dampness and moisture ingress.

A well-known and trusted product in New Zealand, Bituthene® 3000 has been used for decades across a wide range of construction projects, from residential basements and retaining walls to large-scale developments.

Bituthene® 3000 is a reliable choice for positive-side below-ground applications, offering performance and proven quality in challenging site conditions. Bituthene® 3000 is suitable for basements and foundation walls and retaining walls.

Key Features
  • Reliable moisture protection
  • Durable cross-laminated film
  • Cold-applied system
  • Excellent adhesion
  • Flexible performance
  • Consistent quality
  • Compatible system
NZ-Owned Business
NZ-Owned Business
Scope of Use

BITUTHENE® 3000 is a self-adhesive, rubberised asphalt/polyethylene waterproofing membranes, combining a robust, flexible, pre-formed high performance, cross laminated, HDPE carrier film with a tacky, self-adhesive rubberised asphalt compound specifically designed to adhere to cured concrete surfaces.

Bituthene 3000 has been developed for positive long-term, low maintenance waterproofing of construction features such as:

  • Foundations
  • Basements
  • Lift shafts and pits
  • Underslab
  • Elevated or grade level podiums
Limitations on Use

Not suitable for:

  • Bituthene 3000 should not be applied when temperature is below +10° without consultation with the Nuralite representative
  • Must be stored in a dry place protected from rain, sun, heat and cold temperatures
  • Sun exposure of the product may difficult the removal of the polyethylene non-stick film. In service, maximum temperature should be below 50°C
  • Bituthene 3000 should be kept exposed to the sun for the minimum possible time in order to prevent from UV rays damage. It is recommended to cover Bituthene 3000 within a few hours after application.
Statement of Building Code Compliance
  • Clause B2 DURABILITY: Performance B2.3.1 (a) not less than 50 years.
  • Clause E2 EXTERNAL MOISTURE: Performance E2.3.3.
  • Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1.
EPD
Environmental Product Declaration (EPD)
Documents
Bituthene 3000 Technical Data Sheet
Allco Product Range Brochure
Preprufe and Bituthene Brochure
