Flashings by ACMF

Flashings

Description

Flashings are defined in NZ Building Code clause E2 as ‘components formed from a rigid or flexible waterproof material that drains or deflects water back outside the cladding system. Flashings play a vital role in preventing external moisture from getting through the building envelope and are required in many location of a building.

Key Features

WE SPECIALISE IN THE FOLLOWING MATERIALS:

Aluminium – minimum 0.7 mm thick
Galvanised steel – minimum 0.55 mm thick
Aluminium/zinc alloy-coated steel – minimum 0.55 mm thick
Stainless steel – minimum 0.45 mm thick
Copper – minimum 0.5 mm thick

SURFACE FINISHES

Epoxy Powder Coated up to 25 Year Guarantee
Anodizing

FLASHING LENGTHS

2.4m, 3.0m and 3,6m. 4m on special request

Scope of Use

Roof junctions and edges including gutters
Changes in roof pitch
Roof and wall penetrations such as pipes, doors, windows etc
Vertical and horizontal junctions between cladding materials
Roof and wall intersections including soffits, parapets, skylights and balustrades
Any intersections between different building elements

Limitations on Use

We make bespoke flashings for all projects.

Statement of Building Code Compliance

ACMF supply and install various flashings to the NZ Building code E2 (external Moisture) / B2 (Durability), servicing both residential and commercial. Flashings are made in our own factory located on the North Shore, Auckland.

ACMF are exterior experts, looking after the whole building envelope — cladding, flashings, louvres and screens, balustrades, roofing and fire-rated aluminium joinery.
