Techlam Introduces New Sprucelam Beams for Interiors

Industry experts in structural laminated timber for over 25 years, Techlam saw a gap in the New Zealand market for an aesthetically pleasing, high strength laminated interior product. To fill that gap, Techlam has sourced a better visual grade timber that has superior structural properties to Radiata Pine. It meets appropriate NZ Standards, is more dimensionally stable, is price competitive and environmentally certified.

Not all people want to use treated timber, and in Canada for example, durability of timber is assured primarily through good design, natural resilience of the timber and only lastly timber treatment, ie. if the structure is designed correctly, timber treatment becomes of very minor importance.

Techlam has been careful to consider where and how the product should be used and have sought expert advice on the appropriate design and use of Sprucelam.

Techlam's PASS (Product Technical Statements or PTS) are available for download from the Techlam website and clearly detail the full scope, use and limitations of Sprucelam.

Key Features:

Picea abies is commonly referred to as Spruce, or Norwegian Spruce
Grown in Europe, is commonly used in construction
Used to create durable, engineered structural wood products
Creamy white in appearance with a hint of yellow and/or red
Fine, even texture and a consistently straight grain
The durability of its heartwood is equivalent to that of Douglas Fir

Sprucelam

Techlam NZ

View Product

Sprucelam is an untreated engineered timber product suitable for use as a structural element where the risk of exposure to moisture is minimised.

NZ Made

NZ-Owned Business

Techlam supplies Sprucelam for use as a structural element located within the external envelope of a building or where it forms part of the external structure subject to the same controls applied to untreated Douglas Fir.

Where used as part of the external structure the following scope applies:

In new buildings designed and construction to NZS3604:2011or specifically engineered to NZS3603:1993.
In existing buildings where the designer and installer have determined that the existing building is suitable for the intended building work and that all other conditions have been met, and
In stand alone, single units less than 10m in building height, and
In all corrosion zones, subject to fixings in accordance with section 4, NZS3604:2011
Has a risk matrix score of no more than 6 on any external face, as defined in E2/AS1, and
Has a roof slope of 10° or more, and
If it has a skillion roof, the roofing material is corrugated iron or concrete, metal of clay tiles for adequate ventilation, and
Has eaves or 450mm-wide or more for single-storey buildings and eaves 600mm-wide or more for two storey buildings

If designed, installed and maintained in accordance with all Techlam requirements, Sprucelam will comply with or contribute to compliance with the following provisions of the NZBC:

B1 Structure, B1.3.1, B1.3.2, B1.3.3 (a, b, f, h, j, m, q) - Compliance by Alternative Solution AS/NZS1328:1998 (glulamination) NZS3603:1993A4 (timber structures), NZS3631:1998 (grading) and AS/NZS 5068:2006 (finger jointing).
B2 Durability, B2.3.1(a) - Compliance by B2/VM1 April 2017: Scion TE16-067 – Spruce & Radiata Pine Finger Joint Qualification test & Glue Bond Durability Test. March 2015: Scion Expert Opinion Durability of heartwood Spruce compared to durability of sap/heartwood Douglas fir
F2 Hazardous Building Materials, F2.3.1 — Compliance by In service history
