Achieve Acoustic Comfort Without Pipe Lagging

RAUPIANO PLUS conforms to the BCA/NCC rating for habitable areas without the need for lagging thanks to its dense Mineral Reinforced PolyPropylene composition, modular sound absorbing bends, and sound-dampening brackets that minimise sound transfer between the pipe and building structure.

REHAU RAUPIANO is specified by some of the leading Engineering Consultants across both North and South Islands. Raupiano is Clyne and Bennies preferred acoustic waste pipe system for all their residential/commercial and retirement village projects.

RAUPIANO PLUS has been used in commercial projects including hospitals, apartments, and retirement villages as well as residential applications throughout New Zealand, Australia and Europe. Installers have saved time and materials by using RAUPIANO PLUS for their projects.

RAUPIANO PLUS conforms to the BCA/NCC rating for habitable areas without the need for lagging due to the pipe being made from a dense Mineral Reinforced PolyPropylene, its modular sound absorbing bends and its Sound-Dampening brackets that minimise sound transfer between the pipe and building structure.

RAUPIANO PLUS is an acoustically rated polypropylene drainage system approved for both residential projects and trade waste*. The rubber ring seals provide a faster installation when compared with PVC or HDPE allowing for less time for trades on site. Being acoustically rated also provides the minimum number of trades as laggers are not required to be on site after the plumbers have completed their installation of the drainage.

RAUPIANO PLUS Acoustic Plumbing and Drainage System

REHAU

View Product

The RAUPIANO PLUS Acoustic Plumbing and Drainage System is a polypropylene-based plumbing and drainage pipe system that consists of discharge pipes and fittings that have been acoustically designed to reduce the noise caused by water and waste passing through the discharge system.

The system is suitable in a wide range of buildings from comfortable homes, modern hospitals, and hectic commercial kitchens to contemporary skyscrapers.

The RAUPIANO PLUS Acoustic Plumbing and Drainage System has been appraised by BRANZ for use within the following scope:

as pipes, fittings and materials for sanitary plumbing system design and installation in accordance with NZBC Acceptable Solution G13/AS3 and AS/NZS 3500.2; and
for use as a sanitary plumbing system for internal use within buildings; and
for pipes and fittings of size 40 mm and greater, for drainage system design and installation in accordance with NZBC Acceptable Solution G13/AS3 and AS/NZS 3500.2.

In the opinion of BRANZ, The RAUPIANO PLUS Acoustic Plumbing and Drainage System if designed, installed, used and maintained in accordance with the statements and conditions of Appraisal 809 (2013), will meet the following provisions of the NZBC.

Clause B2 DURABILITY: Performance B2.3.1 [a] not less than 50 years, and B2.3.1 [b] 15 years, and B2.3.2. The RAUPIANO PLUS Acoustic Plumbing and Drainage System meets this requirement. See Paragraph 8.1.
Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1. The RAUPIANO PLUS Acoustic Plumbing and Drainage System meets this requirement and does not present a health hazard to People.
Clause G13 FOUL WATER: Performance G13.3.1 and G13.3.2. The RAUPIANO PLUS Acoustic Plumbing and Drainage System meets these requirements. See Paragraphs 7.1 to 7.5.

BRANZ Appraised
