Proframe - Aluminum Subframe
Description

The Proframe aluminum joist system is the ultimate decking support solution. Designed to support Futurewood composite decking over membrane decks and concrete patios, It's simple and sturdy design ensures rapid installation regardless of the complexity of the project.

Proframe's powder coated aluminium joists are extremely stable and won't warp, cup or bow. Because the aluminium is so stable, end plates and nogs are often not required.

Proframe’s joist/bearer is a low 45mm profile which sits well clear of the membrane not restricting the flow of water off the membrane. Water and debris can easily drain into the gutter and the installation of inspection hatches allows for easy care and maintenance.

Key Features
  • Fast installation — in some cases installation time savings of up to 75% versus traditional timber methods
  • Aluminium joists provide twice the span using half the height of traditional timber, requiring less jacks to support the frame
  • Aluminium weighs a fraction of traditional timber and is far less physically taxing when loading or installing the framing onto the site. Lightweight aluminium can easily be passed up a multi-story scaffold to access difficult areas
  • All frames are designed to a 4kpa commercial deck loading
  • Proframe's system is fully compatible with Futurewood composite decking
  • Both Futurewood and Proframe carry a 15 year, 100% warranty
Categories / Ranges
Decking
Scope of Use
  • Futurewood and Proframe can be used for decking in residential, light commercial and heavy commercial construction
  • The system is ideally suited for use over membranes, concrete patios or above ground up to 400mm
  • All frames are designed to a 4kpa commercial deck loading
  • Proframe's system is fully compatible with Futurewood composite decking
Limitations on Use

The use of a traditional timber and pile subframe to support Futurewood composite decking is recommended when a finished deck height deck is 400mm or higher above the ground.

Other Performance Attributes
  • Both Futurewood and Proframe carry a 15 year, 100% warranty.
Documents
Maintenance Instructions
Warranty
Specification Clause/Guide
Installation Details
Installation Overview
