Designed for concrete & masonry foundation walls and other below grade vertical surfaces. Suitalble for areas with low risk of hydrostatic water pressure, and up to 3m deep below ground.

This product is only suitable for areas with low risk of hydrostatic water pressure, and areas up to 3m deep below ground. For areas with high hydrostatic water pressure, or deeper than 3m we have the Colphene BSW waterproofing system available.

The product must be installed by a Certified Equus Applicator. Verification of their status can be confirmed by a current applicator certificate or by contacting Equus Industries. Any installation must be done in accordance with the latest specifications and technical documentation, or with written approval by Equus Industries Ltd.

• B2 Durability - B2.3.1 (a), COLPHENE 3000 has a durability of at least 50 years where used underground when installed with the correct specification, installation and maintenance.
• E2 External moisture - E2.3.2, E2.3.3, E2.3.7 Test data, together with in-service history in New Zealand and internationally, of the correctly installed COLPHENE 3000 membrane over correctly designed and constructed substrates, show that the membrane successfully resists the ingress of moisture.
• F2 Hazardous building materials - F2.3.1 Well known experience with the type of materials used together with in-service history, show that COLPHENE 3000 complies with this performance requirement. Refer to SDS at www.equus.nz

For full details see BRANZ Appraisal 1037
