ABLOY Protec2 CLIQ by ASSA ABLOY

ABLOY Protec2 CLIQ

ASSA ABLOY

All products

Product Enquiries

Description

The multi-award winning ABLOY® PROTEC2 CLIQ and CLIQ WEB MANAGER with CLIQ REMOTE is a combination of the proven, ABLOY® PROTEC2 mechanical keying system and the CLIQ electronics developed by ASSA ABLOY.

ABLOY® PROTEC2 CLIQ offers the ultimate synergy between the tried-and-true reliability of the superior mechanical ABLOY® PROTEC2 and the programming ease and flexibility inherent in electronic locks and keys. ABLOY® PROTEC2 CLIQ is a true one key solution where CLIQ keys are able to operate both the electromechanical and mechanical cylinders.

ABLOY® PROTEC2 CLIQ is a very cost effective solution. CLIQ cylinders are installed in areas which require electronic features such as audit trails, time limited access and easy blocking of lost keys. Those areas could for instance be the perimeters, storerooms or server rooms. Mechanical ABLOY® PROTEC2 cylinders are then installed in the other areas.

Key Features

Electronic access control without wiring
Cost effective one key solution
Audit trails stored in both keys and cylinders
Flexible access permissions
IP57 Rated CLIQ Keys
IP68 Rated Padlocks
Access permissions can be updated remotely
Cloud (web) based software
Easily replaced standard battery
Dual security; mechanical and electronic
Central management philosophy
Symmetrical 9 Disc with CLIQ Intelligent Electronics

Ranges

Electronic Locking

Scope of Use

ABLOY® PROTEC2 CLIQ is used in various industries worldwide.

Transportation and Logistics
Government and Institutional
Water, Energy and Communications
Education and Healthcare
Industrial and Commercial
Museum and Heritage

Complete Product Range:

ABLOY®PROTEC2 CLIQ offers a wide range of locks for all types of applications.
The range includes cylinders for doors, safes and cabinets, padlocks, office locks and cam locks.

Other Performance Attributes

Software and Management:

CLIQ WEB MANAGER s the new user-friendly, cloud (web) based, software to manage CLIQ master keying systems. CLIQ WEB MANAGER provides easy, secure and flexible management of keys and cylinders.
Administrators can connect to CLIQ WEB MANAGER via the internet form anywhere in the world and easily change the access rights for the user keys.
The key holders can then update their keys via network connected CLIQ REMOTE programming devices placed on a wall or connected to a mobile phone.
All communication with CLIQ WEB MANAGER is encrypted and a personal PIN code protected CLIQ C-key as well as a certificate in the web browser is required to login to the software.
CLIQ WEB MANAGER with CLIQ REMOTE enables many of the tasks involved in the management of an electronic master keying system to be done automatically.
Access right changes, audit trails collection and key validity extensions are examples of such tasks.
CLIQ WEB MANAGER with CLIQ REMOTE often eliminates the need to service locks on site.

CLIQ Intelligent Electronics:

CLIQ is based on electronics that can be embedded directly inside the key and the core of a cylinder.
Each ABLOY® PROTEC2 CLIQ key and cylinder contains a unique electronic code, designated for one individual element only and cannot be altered or corrupted.
A replaceable battery is inserted into the key and serves as the sole power source.
The electronic mechanism embedded in the cylinder, is a self-contained unit.
This translates into no wiring whatsoever. Consequently, the intelligent cylinder installs with ease like any normal cylinder.

Operating Principle:

The use of ABLOY®PROTEC2 CLIQ keys and cylinders is nearly the same as the use of a normal mechanical locking system.
The only difference is the sound signals given to the key holder when a CLIQ key is inserted in a CLIQ cylinder.
The electronics in the key and cylinder cause a small delay of 0.4 seconds before the key can be turned after the key insertion.
