Volclay Voltex Suitable for Harsh Weather Conditions

Voltex is a highly effective waterproofing composite of high strength geotextiles.

Installation of Voltex is fast and easy — simply position the product into place and fasten. Voltex can be installed on green concrete, is designed for use in the basement environment (wet and dirty) and is able to be installed in virtually any weather, without the need for primers or adhesives.

Voltex can be easily cut on site to form around corners and penetrations. The result is always a consistent self-healing membrane.

Volclay Voltex DS & DS/SWR

Allco Waterproofing Solutions

View Product

Bentonite-Geotextile waterproofing system with Integrated Polyethylene Liner, used as a damp-proofing or waterproofing membrane below ground to protect basements and other underground structures against water penetration and water vapour transmission from the ground.

The Volclay Waterproofing System has been appraised for use as:

an external waterproof tanking membrane to in-situ concrete, precast concrete and concrete masonry basement constructions subject to hydrostatic pressures of up to 2 bar (20 metres); and,
a damp-proof membrane (DPM) to slab-on-ground and basement constructions; and,
a waterproof membrane to plaza deck roof structures

In the opinion of BRANZ, the Volclay Waterproofing System if designed, used, installed and maintained in accordance with the statements and conditions of this Appraisal, will meet the following provisions of the NZ Building Code:

Clause B2 DURABILITY: Performance B2.3.1 (a) not less than 50 years. The Volclay Waterproofing System meets this requirement. See Paragraph 14.1.
Clause E2 EXTERNAL MOISTURE: Performance E2.3.3. The Volclay Waterproofing System meets this requirement. See Paragraphs 16.1 – 16.3.
Clause F2 HAZARDOUS BUILDING MATERIALS: Performance F2.3.1. The Volclay Waterproofing System meets this requirement and will not present a health hazard to people.

This is an Appraisal of the Volclay Waterproofing System as an Alternative Solution in terms of New Zealand Building Code compliance.

Durability

External Moisture

Hazardous Building Materials

BRANZ Appraised
