EcoVersal is suitable for:

• New builds and refurbishment as external or internal continuous insulation
• Direct fixing to concrete and masonry walls
• Steel and timber framing, as external or internal continuous insulation or between studs or rafters
• Light duty under floor insulation between floor joists.

• Cannot be exposed to weather elements.
• Not a component for structural bracing.
• Not a fall arrest product.
• Not a flat roof board for membrane roof systems (see Kingspan Therma products).
• Not to be in direct contact with wet concrete. A separation layer is required.
• Do NOT stand on or support your weight on EcoVersal.

EcoVersal insulation boards meet the performance requirements of NZBC, Clauses B2 Durability (B2.3.1 (a) 50 years), Clause E3 Internal Moisture (contributes to E3.3.1 ), and Clause H1 Energy Efficiency (contributes to H1.3.1 and H1.3.2E) by testing and comparison with acceptable solutions H1/AS1 and H1/AS2 and verification meth ds H1/VM1 and H1/VM2 providing:

• It is not damaged, dented or fractured.
• It is installed in accordance system installation instructions.
• It is installed by or under guidance of Licensed Building Practi tioners.

• Thermal Conductivity at 15C (λ-value) as per AS/NZS 4859.1:2018:  0.024 W/m.K
• 50mm — R2.10
• 80mm — R3.35
• 100mm — R4.30
