Vault Vinyl
Description

When the going gets tough, Belgotex's Vault commercial sheet vinyl flooring is as tough as it gets. With an extra heavy duty wear layer on top, it has been engineered to handle heavy applications with ease. With no need for waxes or polish, Vault will make light work of heavy foot traffic. Along with being highly durable, it is easy to fit, making it the perfect choice for offices and retail use, where a beautiful appearance needs to be combined with the toughest of tough finishes.

Key Features
  • 2mm thick w/- 0.7mm wear layer
  • R10 slip rating
  • 15 year residential warranty
  • 10 year commercial warranty
Scope of Use
  • All building types, including heavy industrial
  • Suitable in accessways
  • Suitable in water-splash areas and within 1.5m of a sanitary fixing
Limitations on Use
  • Interior use only
  • Must be installed by a qualified installer
  • Installation to be undertaken to industry best practice guidelines
  • Must be maintained in line with Belgotex's care and maintenance guidelines
  • Substrate must have 75% or less relative humidity
Statement of Building Code Compliance
  • B2.3.1(c) Alternative Solution, Vault is manufactured to ISO9001 standards and meets the minimum durability requirement of 5 years
  • C3.4(c) Acceptable Solution, Vault has been tested against ISO9239-1 standards achieving a CRF of 9.0kW/m²
  • D1.3.3(d) Acceptable Solution, Vault has been tested to an R10 slip rating using DIN51130:2014 testing standards
  • E3.3.3, E3.3.5 Acceptable Solution, Vault is an acceptable solution and an integrally waterproof sheet material as defined under E3/AS1 3.1.1(a)
  • F2.3.1 Verification Method, Vault is Floorscore certified
In-Service History

Belgotex sheet vinyl has been installed in building in New Zealand for over 5 years, with most original installations still in service.

Other Performance Attributes
  • 15 year residential warranty
  • 10 year commercial warranty
  • R10 slip rating
  • Floorscore certified
B2 Durability compliant
Durability
C Protection from Fire compliant
Protection from Fire
D1 Access Routes compliant
Access Routes
E3 Internal Moisture compliant
Internal Moisture
F2 Hazardous Building Materials compliant
Hazardous Building Materials
Documents
Data Sheet

13/09/2023

Fire Testing

27/09/2018
