ACO MiniKlassik Drainage System

MiniKlassik is a compact trench drainage system for high profile, small-scale projects where a barrier is required to separate wet and dry areas. A choice of Heelsafe® Anti-Slip grates are available in stainless steel and ductile iron.

Key Features
  • Narrow width: 50mm internal width and 85mm overall depth
  • Manufactured from durable Polymer Concrete
  • Interconnecting end profiles for easy joining of channels
  • Profiled side walls for high channel body strength
  • Heelsafe® Anti-Slip grates to AS 3996, AS 1428.2 and AS 4586



Scope of Use

Small trench drain systems for regularly foot trafficked balconies or pavements where a discrete barrier is required to separate wet and dry areas.

  • Narrow width: 50mm internal width and 85mm overall depth
Other Performance Attributes
  • Grates have been load tested in accordance with AS 3996 guidelines up to Class D (8 tonnes vehicles).
  • Wheelchair compliant to AS 1428.2, Clause 9(c). Slots cannot exceed 13mm (width), 150mm (length). Longitudinal grates are to be placed at right angles to the principal direction of travel.
  • Grates designed to resist the penetration of a 10mm heel.
  • Bicycle tyre penetration resistant to AS 3996. Criteria on slot length dependant on slot width.
  • Pedestrian safe grates with slip resistance, rated to AS 4586.
Additional Information

ACO are a world market leader in drainage technology with innovative solutions to new environmental conditions.
