ACMF Aero Louvres
Description

The ACMF Aero Louvres are an advanced architectural shading system designed to combine cutting-edge technology with exceptional aesthetics. These louvres provide effective rain, privacy, and weather control solutions for building facades.

The system offers compatibility with various louvre configurations, including motorised panels, end fixed, rear fixed, or bracket fixed options. The Aero Louvres are available in a wide range of widths, starting from 120mm and extending up to 800mm, allowing for tailored solutions that meet the specific requirements of designers and end-users.

Key Features
  • Effective rain protection, privacy, and weather control
  • High-quality construction and materials
  • Range of sizes and profiles available
  • Easy integration with various louvre systems
  • Customisable options for specific project needs
  • Wide range of powder coated finishes available
  • Anodising options for enhanced durability and aesthetics
  • Can be used horizontally or vertically
  • Suitable for spans up to 6.5m depending on wind zones
Scope of Use
  • Suitable for interior & exterior applications on commercial, residential, and industrial buildings
  • Compatible with different substrates and systems
  • Applicable in various environments and Very High wind zones
  • Ideal for enhancing aesthetics and providing functional benefits in retail, educational facilities, commercial and residential project
  • End fixed, rear fixed, or bracket fixed options
  • Range of widths, starting from 120mm and extending up to 800mm
Limitations on Use

Not suitable for extreme weather conditions: While Aero Louvres are designed to withstand various weather conditions, there may be limitations in severe weather situations such as hurricanes or cyclones. It is important to assess the specific wind loads and environmental conditions of the installation location.

Statement of Building Code Compliance

ACMF Aero Louvres comply with the following performance clauses of the NZ Building Code:

  • B1: Structure
  • B2: Durability
In-Service History

The Aero Louvres have been successfully used in numerous projects over 25 years. They have demonstrated reliability and performance in various architectural applications.

Other Performance Attributes

Refer to ACMF Nominated Vertical and Horizontal Louvre Spans

Warranty

The Aero Louvres are backed by a 5 year workmanship and 15 year material warranty that covers manufacturing defects and ensures their performance.

Maintenance requirements may include occasional cleaning and inspection to ensure optimal functionality and longevity.

Documents
Aero Lourves Span Tables
Span Tables: All Louvres
ACMF Brochure
Website: ACMF Aero Louvres

ACMF are exterior experts, looking after the whole building envelope — cladding, flashings, louvres and screens, balustrades, roofing and fire-rated aluminium joinery.
