Gerflor Mipolam EL5 Conductive Homogeneous Sheet Vinyl by Belgotex

Gerflor Mipolam EL5 Conductive Homogeneous Sheet Vinyl

Description

Gerflor Mipolam EL5 is a conductive flexible homogeneous commercial sheet vinyl floor covering, incorporating carbon encapsulated granules throughout its full thickness with a conductive backing to ensure optimal and consistent conductive properties throughout its full life expectancy.

Treated with Evercare which avoids staining from chemical products used in healthcare like betadine, eosin or anti-bacterial hand gel and increases the durability of the flooring. This treatment has excellent maintenance characteristics; it requires no wax for life.

Key Features

Conductive flooring: complies with IEC 61340-5-1 & ANSI/ESD S20.20
Low charge potential
High electrical resistance
Comes with Evercare surface treatment for ease of maintenance

Ranges

Gerflor Vinyl Sheet & Tiles

Post-Consumer Recyclable Content

Scope of Use

Suitable in heavy traffic commercial and industrial areas where electrostatic discharge (ESD) protection is required
Suitable in accessways
Suitable in watersplash areas and within 1.5m of a sanitary fixture or appliance

Limitations on Use

Interior use only
Substrate must have a relative humidity of 75% or below
Seams to be welded using Belgotex supplied weldrod
Must be installed according to the Installation Instructions and NZS/AS 1884:2013
Must be installed using the specified adhesive
Must be maintained in line with Belgotex care and maintenance guidelines

Statement of Building Code Compliance

B2.3.1(c): Mipolam EL5 is manuactured to EN 14041 standard and meets the durability requirements of at least 5 years
C3.4(b): Mipolam EL5 has been tested against ISO 9239-1 standard achieving a CRF of 8.6kW/m²
D1.3.3(d): Mipolam EL5 provides acceptable slip resistance for level access routes, slopes, and stairs expected to remain dry under normal use as per D1/AS1 Table 2
E3.3.3, E3.3.5: Mipolam EL5 is considered an integrally waterproof sheet material as defined under E3/AS1, 3.1.1(a)
F2.3.1: Mipolam EL5 is FloorScore certified for low VOC emissions

In-Service History

Gerflor, founded in 1937 and inventor of homogeneous vinyl flooring, have been providing market leading quality products for over 85 years.

Other Performance Attributes

Electrical resistance: 10^4 ≤ Rt ≤ 10^6 Ω (EN 1081)
Static electrical propensity: <100V (IEC 61340-4-5, ESD shoes)
Slip Resistance - Wet Pendulum: P2 (AS 4586-2013, Appendix A)
Slip Resistance - Oil Wet Ramp: R9 (EN 16165:2021, Annex B)
Class 34 Commercial Very Heavy / Class 43 Industrial Heavy
12 Year Commercial Warranty
100% recyclable
May contribute points toward Green Star or Homestar certification
Green Star Responsible Product Value (RPV): 10 — achieved through Product-Specific EPD and Science-Based Targets initiative (SBTi) - Targets Set
