Aliwood — Aluminium Wood-Look Screening
Description

Specialists in designing and manufacturing a range of screening and facade systems to create great wood-look solutions for various applications. Aliwood screens are made in a number of common sizes to suit most projects.

The Aliwood Clip On range is believed to be the fastest and easiest installation of an aluminium batten extrusion. The Clip On extrusion is available in several different sizes. These sizes can be mixed and matched to suit the design or preferred final aesthetic. The backing plate is a universal extrusion that suits a range of sizes and can be mounted to any surface by using either screws or bonding the tracking to the facade. Aliwood offers complete flexibility not only in design but also in choices of colours, styles and sizing.

Key Features
  • Non-combustible
  • Ideal timber substitute
  • Easy installation
  • Virtually no maintenance
  • Versatile
  • Lightweight
  • Variety of colour
  • Sustainable
  • Rot and pest resistant
  • Mould resistant
  • Hidden shiplap fixing system
  • Over 13 years' experience
  • Over 13 years' experience
  • 15mm Clip On option
    The standard aluminium channel is fixed to a wall of a maximum of 450mm centres. This installation allows for 3 different sized visible pieces to clip to it. The clip on fixing offers a clean and concealed look with the possibility of an express line finish. It is ideal for applications such as ceilings, feature walls and garage doors.
  • 30/50mm Clip On option
    The standard backing of 30/50mm wide is available for 3 different depths. The system is fixed by simply locking the front piece and the backing piece together. This offers a clean line where the battens can be set out to any desired spacing. This system is ideal for privacy screens, fencing, feature walls and any conventional walls.
Scope of Use
  • Residential and commercial applications
  • Health / aged care facilities
  • Educational institutions
  • Hospitality sector
  • Fit outs
  • Retail and shopping centres
  • Bush fire prone areas
  • Ceilings
  • Feature walls
  • Garage doors
  • Privacy screens
  • Fencing
  • Most conventional walls

15mm Clip On option:

  • The standard aluminium channel is fixed to a wall of a maximum of 450mm centres
  • This installation allows for 3 different sized visible pieces to clip to it
  • The clip on fixing offers a clean and concealed look with the possibility of an express line finish
  • It is ideal for applications such as ceilings, feature walls and garage doors

30/50mm Clip On option

  • The standard backing of 30/50mm wide is available for 3 different depths
  • The system is fixed by simply locking the front piece and the backing piece together
  • This offers a clean line where the battens can be set out to any desired spacing
  • This system is ideal for privacy screens, fencing, feature walls and any conventional walls
Statement of Building Code Compliance

All designs are made to exact specifications, and stringently tested and certified to Australian Standards.

Fire Test Report:

  • AS/NZS 1530.3:1999 Simultaneous determination of ignitability, flame, propagation, heat release and smoke release
  • AS/NZS 3837 Method of test for heat and smoke release rates for materials and products using an oxygen consumption calorimeter, 1998, at 50 kW/m²
Other Performance Attributes
  • Virtually no maintenance
  • Sustainable
  • Rot and pest resistant
  • Mould resistant
Documents
Test Results
Test Results
Installation Instructions: 15mm Clip On
Installation Instructions: 30/50mm Clip On
Brochure
Additional Information

Importer and distributors of shingle roofing, cladding, screening and lining across New Zealand, with brands including Owens Corning, Innowood, Aliwood, Equitone, Frontek and Alucobond.
