Concept Ultimate Vinyl
Description

The Concept Ultimate collection offers the largest available selection of commercial decorative vinyl flooring solutions. In wood patterns, classic and fun colours and modern designer variants. Concept is a super-compact quality flooring with a top layer of 0.70mm additionally reinforced by a PU layer that provides the highest possible degree of protection in areas with a lot of traffic. The floor is especially hygienic thanks to the antibacterial sanitec treatment.

Key Features
  • 2mm thick w/- 0.7mm wear layer
  • R10 slip rating
  • 10 year residential warranty
  • 5 year commercial warranty
Scope of Use
  • All building types, including heavy industrial
  • Suitable in accessways
  • Suitable in water-splash areas and within 1.5m of a sanitary fixing
Limitations on Use
  • Interior use only
  • Must be installed by a qualified installer
  • Installation to be undertaken to industry best practice guidelines
  • Must be maintained in line with Belgotex's care and maintenance guidelines
  • Substrate must have 75% or less relative humidity
Statement of Building Code Compliance
  • B2.3.1(c) Alternative Solution, Concept Ultimate is manufactured to ISO9001 standards and meets the minimum durability requirement of 5 years
  • C3.4(c) Acceptable Solution, Concept Ultimate has been tested against ISO9239-1 standards achieving a CRF of 11kW/m²
  • D1.3.3(d) Acceptable Solution, Concept Ulttimate has been tested to an R10 slip rating using DIN51130:2014 testing standards.
  • E3.3.3, E3.3.5 Alternative Solution, Concept Ultimate has been tested to ISO4760:2022, is impervious and easily cleaned
  • F2.3.1 Verification Method, Concept Ultimate is REACH certified
In-Service History

Belgotex sheet vinyl has been installed in building in New Zealand for over 15 years, with most original installations still in service.

Other Performance Attributes
  • 10 year residential warranty
  • 5 year commercial warranty
  • R10 slip rating
  • REACH certified
B2 Durability compliant
Durability
C Protection from Fire compliant
Protection from Fire
D1 Access Routes compliant
Access Routes
E3 Internal Moisture compliant
Internal Moisture
F2 Hazardous Building Materials compliant
Hazardous Building Materials
Documents
Data Sheet

12/09/2018

Fire Testing

03/12/2014
