dbBatten Acoustic Battens
Description

dbBatten™ range is a modular acoustic batten designed for function with modern aesthetic. It is suitable to be installed direct to both ceiling and wall via a patent-pending, glue-free and DIY Ready-Clip™ install system. Made from 100% polyester fibre, of up to 60% recycled content, dbBattens are light weight and non-irritant, can be direct fixed or rafted and suspended for exceptional sound absorption.

As well as being simple to install, dbBatten can be removed and re-purposed with minimal fuss, reducing waste and improving the sustainability of interior finishes.

Key Features
  • Precise installation
  • Improved acoustics: audibly reduces reverberation time.
  • Visual Impact: variety of available material colours offering ~78% light reflectance
  • NZ made
  • Customisable prints — panels can be subtle or a feature design
  • Durable panel construction with high impact resistance provides long-term stability and performance
Recycled Content (Pre-Consumer)
Pre-Consumer Recycled Content
Scope of Use
  • Suitable for ceilings & walls
  • Commercial interiors, offices, schools & education
  • Direct fixed or rafted and suspended for exceptional sound absorption
  • Installed via patent-pending, glue-free and DIY Ready-Clip™ install system
Other Performance Attributes
  • Up to 60% recycled content
  • NRC: 1.05
  • Antibacterial
  • No loose fibres, non-toxic, non-irritant, glue-free, Low VOC
  • Fire Rating 12mm: EN 13501-1:2018: B - s1, d0
  • Environmental Global Recycled Standard (GRS) 4.0
  • OEKO-TEX® Confidence In Textiles STANDARD 100
Documents
dbBatten Acoustic Battens Data Sheet
dbBatten Acoustic Battens Installation Guide
Additional Information

Comfortech Building Performance Solutions® is a business that engineers’ solutions for comfort, climate, and protection.
